VPM-60x80x4/24-COMPO

  • d (h9)
  • D (H9)
  • Material
  • H1+0.2
  • C/S
  • Stack Height (H/V)
  • Unit

$ 94.22
$ 75.37 75.37 AUD

$ 94.22

Quantity
Your Price
1 - 4
$ 75.37
5 - 9
$ 71.60
10 - 24
$ 67.83
25 - 49
$ 61.24
50 +
$ 47.11

This combination does not exist.

Add to Cart

VPM 60 X 80 X 4 / 24 COMPO

Details:

d (h9)
:
60mm
H1+0.2
:
24mm
C/S
:
10mm
Stack Height (H/V)
:
4mm
D (H9)
:
80mm
Material
:
COMPO
VPM-60x80x4/24-COMPO

Design

  • VPM vee packer seal is normally used in multiples in a set with male and female adaptors. The parts are 'stacked' together and are lubricated liberally with clean operating fluid prior to assembly. VPM must be axially pre-loaded by the housing. This pre-load works through the male adaptor on the pressure side, exerting a hinging action, forcing the sealing lips apart to ensure a low pressure seal. As pressure and hinging action increases, it increases the effectiveness of the seal even where severe vibration may occur.


Applications

  • High pressure rod and piston sealing applications
  • Used in steel mill and hydraulic press applications


Fluids

  • Mineral based oils, water/glycol and water emulsions
